Complete turnkey 0.6kW solar pumping package (DUMAC-SOL-48 DC MPPT Solar) delivering up to 4.5 m3/h (75 L/min) and 80m maximum head (1.25″ outlet). Includes stainless steel submersible pump, MPPT controller, 2x solar panels (1180W array), and PM2-XL pole-top mounting frame. Ideal for: Shallow/medium stock or house bore, 20-50 m.
Kit Inclusions & Technical Specifications:
– Model / SKU: DUMAC-SOL-3SSC4.5-80-48-600
– Pump Motor Rating: 0.6 kW Brushless Permanent-Magnet Solar Motor
– Controller Type: DUMAC-SOL-48 DC MPPT Solar (MPPT window 60-90V, Max input 110V)
– Maximum Flow Rate: 4.5 m3/h (75 L/min)
– Maximum Total Head: 80 metres
– Discharge Outlet: 1.25″ BSP
– Solar Array Included: 2x Tier-1 Solar Panels (1180W total array, Voc 88.0V, Vmp 74V)
– Pole Mount Included: Heavy-duty PM2-XL pole-top mounting rack + DC isolator, MC4 leads & float switch
– Recommended Application: Shallow/medium stock or house bore, 20-50 m
– Backed by W&P Pumps Kyabram (03 5853 2653). Optional European DAB S4 Solar upgrade also available.
